Phonic SEM712A User Manual

7 SEM710 / SEM712 / SEM712A / SEM715 / SEM715A / SE705 / SE725
SPECIFICATIONS
SEM 710 SEM 712 SEM 715 SEM 712A
Type 2-way Stage/Floor Monitor Speaker
Power Handling (Watts) RMS / Program 80 / 160 150 / 300 200 / 400 -
Built-in Amplier (Watts) RMS - - - 180
Woofer Size 10" 12" 15" 12"
Frequency Response 65 Hz ~ 20 kHz 60 Hz ~ 20 kHz 50 Hz ~ 20 kHz 60 Hz ~ 20 kHz
Sensitivity @ 1 W / 1 M (+/- dB) 96 dB 95 dB 98 dB 120 dB
Built-in Crossover Yes Yes Yes Yes
Dispersion Angle (Degrees) 90 x 40 90 x 40 90 x 40 90 x 40
Box Dual Angled Black Carpet
Handles - 2 2 2
Stand Socket 35 mm 35 mm 35 mm 35 mm
Nominal Impedance 8 ohm 8 ohm 8 ohm -
Connector 2 x 1/4" phone jacks 2 x 1/4" phone jacks 2 x 1/4" phone jacks XLR + 1/4" phone jacks
Dimensions (HxWxD) 491 x 351 x 314 mm
(19.3" x 13.8" x 12.4")
540 x 376 x 356 mm
(21.3" x 14.8" x 14")
679 x 476 x 388 mm
(26.7" x 18.7" x 15.3")
540 x 376 x 356 mm
(21.3" x 14.8" x 14")
Net Weight 11 kg (24 lbs) 13 kg (29 lbs) 19 kg (42 lbs) > 13 kg (29 lbs)
SEM 715A SE 705 SE 725
Type 2-way Stage/Floor Monitor Speaker 2-way Stage Speaker 2-way Stage Speaker
Power Handling (Watts) RMS / Program - 150 / 300 300 / 600
Built-in Amplier (Watts) RMS 180 - -
Woofer Size 15" 15" 15" x 2
Frequency Response 50 Hz ~ 20 kHz 50 Hz ~ 20 kHz 40 Hz ~ 20 kHz
Sensitivity @ 1 W / 1 M (+/- dB) 122 dB 95 dB 100 dB
Built-in Crossover Yes Yes Yes
Dispersion Angle (Degrees) 90 x 40 90 x 40 90 x 40
Box Dual Angled Black Carpet Black Carpet
Handles 2 2 2
Stand Socket 35 mm 35 mm -
Nominal Impedance - 8 ohms 4 ohms
Connector XLR + 1/4" phone jacks 2 x 1/4" phone jacks 2 x 1/4" phone jacks
Dimensions (HxWxD) 679 x 476 x 388 mm
(26.7" x 18.7" x 15.3")
740 x 485 x 334 mm
(29.1" x 19.1" x 13.1")
1085 x 476 x 388 mm
(42.7" x 18.7" x 15.3")
Net Weight > 19 kg (42 lbs) 22.3 kg (49 lbs) 36.5 kg (80 lbs)

Phonic SEM712A Specifications

General

Brand	Phonic
Model	SEM712A
Category	Speakers
Language	English
