Phonocar Five line PH540 - Page 11

TIPOLOGIE
IMPIANTI
TTYPES OF
SYSTEMS
TYPOLOGIE DES
EQUIPMENTS
VERBINDUNGS
VORSCHLÄGE
TIPOLOGÍA DE
LOS EQUIPOS
PH540 - PH560 - PH590 - PH5130
CONNECTIONS
PH544 - PH564
CONNECTIONS
FUSE
POWER
SPEAKERS
BRIDGE
LR
FRONT
REAR
+12V
REM GND
2÷8 Ω 2÷8 Ω
2÷8 Ω 2÷8 Ω
FUSE
POWER
SPEAKERS
BRIDGE
LR
FRONT
REAR
+12V
REM GND
2÷8 Ω 2÷8 Ω
4÷8 Ω 4÷8 Ω
4÷8 Ω
FUSE
POWER
SPEAKERS
BRIDGE
LR
FRONT
REAR
+12V
REM GND
4÷8 Ω
2÷8 Ω 2÷8 Ω
STEREO +
TRIMODE
STEREO
STEREO +
BRIDGE
2÷8 Ω 2÷8 Ω
BRIDGE
FUSE
+12V
REM GND
POWER
SPEAKERS
LR
BRIDGE
FUSE
+12V
REM GND
POWER
SPEAKERS
LR
4÷8 Ω 4÷8 Ω
4÷8 Ω
BRIDGE
FUSE
+12V
REM GND
POWER
SPEAKERS
LR
4÷8 Ω
STEREO +
TRIMODE
STEREO
BRIDGE
