Phonocar Five line PH540 - Caratteristiche Tecniche; Specifications

MODEL PH 540 PH 560 PH590
Channels 222
POWER
Stereo Watt Max 4Ω 80 x 2 120 x 2 180 x 2
Stereo Watt Rms 4Ω 40 x 2 60 x 2 90 x 2
Mono Watt Rms 4Ω 125 190 250
Frequency response 10 Hz÷30 KHz 10 Hz÷30 KHz 10 Hz÷30 KHz
THD < 0,2% < 0,2% < 0,2%
Signal noise ratio > 96 dB > 96 dB > 96 dB
Input High sensitivity 150 mV / 5 V 150 mV / 5 V 150 mV / 5 V
Input Low sensitivity 50 W max 50 W max 50 W max
Load impedance 2 ÷ 8 Ohm 2 ÷ 8 Ohm 2 ÷ 8 Ohm
Bass-Boost __ 0 ÷ 12 dB 0 ÷ 12 dB
Power supply Volts 14,4V (10÷15,6) 14,4V (10÷15,6) 14,4V (10÷15,6)
Fuse 15 A 25 A 2 x15 A
CROSSOVER ADJUSTABLE 12 dB / Oct.
High pass 40 ÷ 200 Hz 40 ÷ 200 Hz 40 ÷ 200 Hz
Low pass 40 ÷ 200 Hz 40 ÷ 200 Hz 40 ÷ 200 Hz
Dimensions (L-H-P) mm. 235 -56 - 170 235 - 56 - 220 235 - 56 - 280
