Phonocar VM002 - Connections; Power and Speaker Outputs with SWC; Pre-Amp Audio;Video Outputs

4
IT-EN
Connessioni • Connections
2
1
USCITE PRE-AMP
PRE-AMP OUTPUT
ALIMENTAZIONE - USCITE ALTOPARLANTI / POWER-SUPPLY - SPEAKERS OUTPUT
SWC*
1
2
4 6 7
3
5
GPS
ANTENNA
AERIAL / FM/AM
VERDE-BIANCO/GREEN-WHITE
GRIGIO-BIANCO/GRAY-WHITE
NERO/BLACK
MARRONE/BROWN
BLU/BLUE
KEY 1
KEY 2
KEY GND
BACK
P.ANT
BIANCO/WHITE
ROSSO/RED
BLU/BLUE
VERDE / GREEN
GIALLO/YELLOW
GIALLO/YELLOW
GIALLO/YELLOW
GIALLO/YELLOW
ROSSO/RED
BIANCO/WHITE
POSTERIORE SINISTRA / REAR LEFT
POSTERIORE DESTRO / REAR RIGHT
AUX-IN SINISTRA / LEFT
AUX-IN DESTRO / RIGHT
NON ABILITATO / NOT ENABLED
USCITA SUB WOOFER / SUB-WOOFER OUTPUT
NON ABILITATO / NOT ENABLED
USCITA VIDEO / VIDEO OUTPUT
INGRESSO VIDEO / VIDEO INPUT
INGRESSO CAMERA FRONTALE / FRONT CAMERA
RL OUT
RR OUT
AUX-IN L IN
AUX-IN R IN
MICROFONO
SUB OUT
VIDEO TV CVBS
VIDEO OUT
AUX VIDEO IN
FRONT CAM
Line 1 SWC*
Line 2 SWC*
Ground for SWC*
Rear-camera activation
+12V reverse light
Aerial power
+ amplier
Linea 1 SWC*
Linea 2 SWC*
Massa SWC*
Attivazione retrocamera
+12V luce retromarcia
Accensione antenna
+ amplicatore
*SWC: Comandi al Volante / Steering Wheel Commands
