18
ENVM053 / VM053E / VM053K
3 CONNECTIONS
3.1 POWER WIRING HARNESS - MEDIASTATION AND SPEAKERS (ISO CONNECTOR), REAR-VIEW
CAMERA ACTIVATION, RESISTIVE STEERING-WHEEL CONTROLS
WARNING!
THERE IS NO ‘GND’ CABLE, USE THE BLACK GROUND CABLE IN THE ISO
CONNECTOR TO USE THE STEERING WHEEL CONTROLS
1
2
2
3
4
576
AM/FM
9
KEY1 KEY2
REVERSE
CAMERA
ISO CONNECTOR
RESISTIVE
STEERING-WHEEL
CONTROLS
RESISTIVE STEER-
ING-WHEEL CONTROLS
ACTIVATION
REAR-VIEW
CAMERA
POWER SUPPLY AND OUTPUTS
SPEAKERS
