ENVM053 / VM053E / VM053K
4
ANTENNA
WI-FI
CAMERA BRAKE
REAR-VIEW CAMERA INPUT RCA PARKING BRAKE SIGNAL
3.4 WIRING HARNESS - REAR-VIEW CAMERA INPUT RCA, PARKING BRAKE SIGNAL, WI-FI ANTENNA
WARNING!
DO NOT CONNECT the indicated blue wires; they serve as a WI-FI
antenna.
Use the Type A USB adapter cable to set it up freely in the passenger compartment.
3.5 TYPE A USB ADAPTER CABLE 6 PIN
3.6 TYPE A USB ADAPTER CABLE 4 PIN
7
6
10
Use the Type A USB adapter cable to connect the DAB+ device (10)
or to set it up freely in the passenger compartment.
