“CONSOLE TROUBLE SHOOTING GUIDE“
The LCD
Screen
Partially
Displays
1. The connection between the
Circuit Board and the LCD
Membrane is loose.
2. Gently press down on the LCD
Screen, if the partial display
disappears, then it is a
connection problem
Verify that the Circuit Board is securely fastened to the Computer
Case. Retighten the Screws. Take care NOT to over tighten the
Screws as this may destroy the Circuit Board. You just need to keep
the Circuit Board firm, STOP tightening screw when you meet
resistance
The Rubber Membranes between the
Circuit Board and the LCD Screen is
misaligned/not in a same line. You
might be able to see that the LCD
Screen is on a slight angle and NOT
inline or parallel with the Console
Cover
2. Remove the Circuit Board’s Screws, gently remove the Circuit
Board, Re-align the LCD screen and the Rubber Membrane.
3. Reassemble the Circuit Board and taking care not to bump or
knock the Rubber Membrane out of alignment before the Circuit
Board Screws are tight. You just need to keep the Circuit Board
firm, STOP tightening screws when you meet resistance
To Next Page
