Chapter 8 : TECHNICAL SPECIFICATIONS
The technical specication details of Premier Combo Plus Digital
TENS/EMS are as follows:
MECHANISM TECHNICAL DESCRIPTION
01 Channel Dual, isolated between channels
02 Pulse Amplitude Adjustable, 0-100 mA peak into 500 ohm
load each channel.
03 Wave Form
Asymmetrical Bi-Phasic Square Pulse
04 Voltage 0 to 50V (Load: 500 ohm)
05 Power source One 9 Volt Battery.
06 Size 11.8cm(L) x 6 cm(W) x 3.1cm(H)
07 Weight 157 grams with battery.
08 Pulse Rate Adjustable, from 2 to 150 Hz, 1 Hz/step
09 Pulse Width Adjustable, from 50 to 300 microseconds,
10 µs/step
10 On Time Adjustable, 2~90 seconds , 1 Sec./ step
11 Off Time Adjustable, 2~90 seconds , 1 Sec./ step
12 Ramp Time Adjustable, 1~8 seconds, 1 Sec./ step, The
“On” time will increase and decrease in
the setting value.
13 Mode Six TENS Modes: B(Burst), N(Normal),M
(Modulation Rate & Width),S1( Modulation
Width), S2 (Modulation Width) and P
Three EMS Modes:C(Constant), S
(Synchronous), A(Alternate)
14 Burst Mode Burst rate: Adjustable, 0.5 – 5Hz
Pulse width adjustable, 50~300µs
Frequency xed = 100 Hz
15 Normal Mode The pulse rate and pulse width are
adjustable. It generates continuous
stimulation based on the setting value.
16 Modulation Mode Modulation mode is a combination of pulse
rate and pulse width modulation. The pulse
rate and width are automatically varied in
a cycle pattern. The pulse width is
decreased by 50% from its original setting
BACK
SIDE
BACK
(10) BELT CLIP
(11) BATTERY STRIP
(12) BATTERY CASE
SIDE
(13) KEY LOCK FACILITY
Liquid Crystal Display
1. INTENSITY LEVEL
2. MODE
3. SETTINGS
4. STIMULATION TYPE
5. LOW BATTERY INDICATOR
6. LOCK
