PIAGGIO Liberty 50IE 2018 User Manual

03_07
Spark plug dismantlement (03_07, 03_08, 03_09, 03_10, 03_11,
03_12, 03_13)
To remove the spark plug, proceed as follows:
- Lift the saddle and undo the cover upper fixing screw from both sides of the vehicle.
03_08
- Undo the spark plug access cover lower fixing screws from both sides of the vehicle.
03_09
- Remove the spark plug access cover.
41
3 Maintenance
