SERVICE STATION MANUAL
1Q000267 EN
MP3 500 i.e. SPORT Business_LT_ ABS-
ASR_EU_USA (2015)

Table of Contents

Questions and Answers

  • A
    Alexis HarrisAug 2, 2025
    Why is my PIAGGIO MP3 500 i.e. SPORT Scooter consuming excessive oil and producing exhaust smoke?
    • M
      markspencerAug 2, 2025
      Excessive oil consumption and exhaust smoke in your PIAGGIO Scooter can stem from several issues: * Incorrect valve adjustment: Adjust the valve clearance properly. * Overheated valves: Remove the head and valves, then grind or replace the valves. * Misshapen or worn valve seats: Replace the head unit. * Worn cylinder, or worn or broken piston rings: Replace the piston cylinder assembly or piston rings. * Oil leaks from couplings or gaskets: Check and replace the gaskets, or restore the coupling seal. * Worn valve oil seal: Replace the valve oil seal. * Worn valve guides: Check and replace the head unit if required.
  • L
    Linda HernandezAug 15, 2025
    What to do if my PIAGGIO MP3 500 i.e. SPORT Scooter has insufficient lubrication pressure?
    • D
      David StoutAug 15, 2025
      If your PIAGGIO Scooter has insufficient lubrication pressure, consider these potential causes: * The By-Pass remains open: Check the By-Pass and replace it if required, carefully cleaning the By-Pass area. * Oil pump with excessive clearance: Perform dimensional checks on the oil pump components. * Oil filter is too dirty: Replace the cartridge filter. * Oil level is too low: Restore the level by adding the recommended oil type.

Summary

Characteristics

Engine Technical Data

Comprehensive technical data for the vehicle's engine specifications.

Maintenance

Scheduled Maintenance Table

Table outlining scheduled maintenance tasks by mileage.

Troubleshooting

Engine

Troubleshooting for engine issues like oil consumption and lubrication.

Transmission and brakes

Troubleshooting for clutch and brake system problems.

Steering and suspensions

Troubleshooting for steering and suspension issues.

Electrical System

Immobiliser

Explanation of the immobilizer system and its components.

Fuses

Information on the location and specifications of fuses.

Engine from Vehicle

Removal of the engine from the vehicle

Procedure for safely removing the engine from the vehicle.

Engine

Removing the clutch

Detailed steps for removing the clutch assembly.

Removing the cylinder head

Procedure for removing the cylinder head.

Removing the cylinder - piston assy.

Steps for removing the cylinder and piston assembly.

Inspectng the crankshaft components

Checking crankshaft component clearances.

Inspectng the crankcase halves

Checking crankcase halves for deformations and lubrication.

Oil pump

Procedures for removing and refitting the oil pump.

Injection

Precautions

Important safety precautions before working on the injection system.

Troubleshooting procedure

Guide for diagnosing engine starting and running issues.

Suspensions

Wheel alignment

Procedure for checking and adjusting wheel alignment.

Shock absorbers

Procedures for removing and refitting shock absorbers.

Braking System

ABS

Operating diagram and general considerations for the ABS system.

Guide to diagnosis

Procedures for diagnosing ABS system faults.

Cooling System

Water pump

Procedures for removing and refitting the water pump.

Chassis

Pre-Delivery

PIAGGIO MP3 500 i.e. SPORT Specifications

General IconGeneral
Engine TypeSingle-cylinder, 4-stroke
Displacement493 cc
Fuel SystemElectronic fuel injection
Max Torque45.5 Nm @ 5, 000 rpm
TransmissionCVT with torque server
Front SuspensionArticulated quadrilateral
Rear Brake240 mm disc
Fuel Capacity12 liters
Seat Height790 mm
Wheelbase1, 550 mm
Width800 mm
Max Power28.5 kW (38.7 HP) at 7, 250 rpm
Rear SuspensionHydraulic shock absorber
Front Brake2 x 258 mm discs
Front Tire120/70-14
Rear Tire140/70-14
