Pickle-ball Kollectaball Max - Required Tools for Assembly

Before assembly, the following
tools are required:
1. Protective Eye wear
2. Flat Head Screwdriver
3. Pliers
1. Cone (R127) x 2
2. Wire Mounting Disk
(R090) x 2
3. Cage Holder (R182)
4. Wire Opener (R195)
5. Stand (R227)
6. Wire (R101) x 62
7. Handle Lower Section
(R211)
8. Handle Upper Section
(R210)
9. Coupler (R219,
Inside Handle)
10. Allen Key
11. Wrench
12. Wire Removal Tool
(R062)
13. Cam (R235)
14. Screw (R050) x 2
15. Hex Screw (R198)
16. Bolt (R197) x 2
17. Washer (R178) x 2
18. Lock Nut (R137) x 7
1 2
3 4
5
6 7 8
9
10
11 12 14 15 16 17 18
13
1
2 3
