31
SERIES FE
LOW-PRESSURE GAS REGULATOR | DESCRIPTION AND OPERATION | REV. 00
EN
Use, maintenance and warning manual
Type
Inlet connection
(modular connections on
request)
Outlet connection
(modular connections on
request)
FE T 1 G ½” EN ISO 228/1 1 G 1” EN ISO 228/1
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
IN
OUT
OUT
FE Q 2 G ½” EN ISO 228/1
• 1 G 1” EN ISO 228/1
(in-line inlet)
• 1 G ¾” EN ISO 228/1
(in-line inlet)
IN
OUT
IN
OUT
IN
OUT
IN
OUT
IN
IN
OUT
OUT
Tab. 4.17.
NOTE!
Mounting positions with the outlet connection facing down are recommended in installations using LPG.
Other versions can be set up according to the safety devices installed:
» slam-shut valve for maximum downstream pressure (always envisaged);
» Excess ow lock-up device (optional);
» relief valve (optional).
