PIETRO FIORENTINI FE25 User Manual

72
SERIES FE
EN
LOW-PRESSURE GAS REGULATOR | CALIBRATION TABLES | REV. 00
Use, maintenance and warning manual
SLAM-SHUT VALVE BP FE6-10-25-S
Pos.
Spring item
code
Spring colour d Lo De
Spring range (mbar)
Min. Max.
1 6447038700 - 1 30 18 25 34
2 64470120BLU Blue 1.1 29 18 35 50
3 64470121GI Yellow 1.3 30 18 51 79
4 64470122VE Green 1.3 36.5 18 80 109
5 64470123ROS Red 1.5 31.5 18 110 159
6 64470124AZ Sky blue 1.6 34 18 160 219
7 64470020MAR Brown 1.7 35 18 220 300
d = Wire Diameter (mm) Lo = Spring Length (mm) De = External Diameter (mm)
Tab. 10.51.
RELIEF VALVE BP FE6-10-25-S
Pos.
Spring item
code
Spring colour d Lo De
Spring range (mbar)
Min. Max.
1 64470389BI White 8 37 15 7 7
2 64470213BL Blue 0.9 37 15 8 10
3
64470029GIA
Yellow 1 35 15 11 19
4
64470027VER
Green 1.2 30 15.4 20 49
5
64470162ROS
Red 1.4 30 15.5 50 75
6 64470024BI White 1.3 45 15 76 120
d = Wire Diameter (mm) Lo = Spring Length (mm) De = External Diameter (mm)
Tab. 10.52.
TR FE6-10-25 EXECUTION
Pos.
Spring item
code
Spring colour d Lo De
Spring range (mbar)
Min. Max.
1 64470368MA Brown 2.4 37 34 180 220
2 64470364GR Grey 2.6 35 34 220 300
3 64470365NE Black 2.8 35 34 300 400
4 64470366VI Purple 3 38 34 400 500
d = Wire Diameter (mm) Lo = Spring Length (mm) De = External Diameter (mm)
Tab. 10.53.
TR FES EXECUTION
Pos.
Spring item
code
Spring colour d Lo De
Spring range (mbar)
Min. Max.
1 64470368MA Brown 2.4 37 34 180 220
2 64470364GR Grey 2.6 35 34 220 300
3
64470365NE Black 2.8 35 34 300 400
4
64470366VI Purple 3 38 34 400 500
d = Wire Diameter (mm) Lo = Spring Length (mm) De = External Diameter (mm)
Tab. 10.54.
