ICN-12-A-A152000-A-S4080-02253-A-001-01
A
GROUND MOORING POINTS
RECESSED RING MOORING POINT
AND CONCRETE MOORING BLOCK
C
A
B
A
B
C
25°
25°
Figure 1-3-1: Aircraft Mooring
Section 1 - Ground Handling
Ground Servicing Guide Report No: 02527
Issue date: Dec 19, 2022
Page 1-3-3
12-A-A15-20-0803-01A-173A-A
