13
33. Keep the horizontal stabilizer and wing spar
parallel. Also keep the vertical stabilizer 90
degrees to the horizontal stabilizer. Hold in
place until glue sets (about 5min). Slight
misalignment can be corrected with the tail
brace wires.
34. Locate the tailwheel assembly bag.
35. Assemble tailwheel as shown. Add a drop
of light oil to aluminum bracket and wire.
Then use 5min Epoxy to glue tailwheel post
into rudder. Make sure it is completely flush
with leading edge of rudder.
36. Test fit the Rudder to the vertical stabilizer.
Move rudder up or down to adjust gap as
shown, approximately 1/16” (2mm).
