14
37. Move rudder to full deflection and use 2-3
drops of thin CA per hinge. Then repeat for
opposite side of hinge.
38. Drill small pilot holes in tailwheel bracket
and install three (3) sheet metal screws.
Test rudder to make sure it moves easily.
39. Use masking tape to hold rudder in center
for installing pull-pull cable. Also, the radio
should also be on or use a servo position
adjuster to hold the rudder servo straight.
40. Install control horn and assemble as shown
on both sides of rudder. Make sure rudder
and servo are centered. Lightly pull slack
from cable. Then crimp aluminum tubes as
shown. .Remove tape from rudder. Cables
should be tightened enough to remove any
slop in the rudder system. Do not over
tighten!
