16
45. Start by cutting the cable into four equal
lengths. Then assemble as shown on one
(1) end of each cable. Position clevis about
half way out on threaded coupler. Note how
the wire is looped twice through the crimp
for safety. Use needle nose pliers to crimp
the aluminum tube.
46. Install the brackets with machine screws
and nuts. Install clevis with wire as shown.
47. Install the brackets with machine screws
and nuts. Assemble unfinished wire end as
shown, pull slack out of wire, and crimp
aluminum tube with pliers.
48. The finished tail brace wires should look like
this.
