17
49. Another photo of the completed lower tail
brace wire and bracket.
50. Locate the landing gear assembly bag.
51. Use aluminum brackets as a guide and drill
1/16” (1.5mm) pilot holes as shown.
52. Install screws for landing gear straps. Do
not install wheels until later to keep plane
more stable during building.
