19
57. Use small drop of blue locktite on each bolt
and tighten. Make sure the bolts do not
extend too far into motor case. See motor
installation manual for more information.
58. Drill pilot holes and install the ESC with
small sheet metal screws on the bottom of
the motor mount.
59. Install the motor mount with the open side
facing up. Route ESC wires through the
firewall.
60. Locate the two pieces of Velcro and trial fit
them like this. These will be used to hold
batteries in place. You may also want to add
a second strap of your own.
To Next Page
