97. With the radio on and all trims centered,
adjust pull-pull cable to center Rudder.
98. Apply full RIGHT rudder and adjust either
mechanically or in radio programming to get
2” (50mm) travel measured at the trailing
edge. Also use 35% exponential to soften
the center travel (consult your radio manual
for how to do this). We recommend a “low
rate” setting of 3/4” (20mm) travel and 20%
exponential.
99. Apply full LEFT rudder and adjust for 2”
(50mm) travel and 35% expo. “Low rate” is
3/4” (20mm) and 20% expo.
100. With the radio on and all trims centered,
adjust pushrods to make ailerons level with
the fixed inboard trailing edge of the wing.
