28
93. Use a 90 degree square to adjust vertical
alignment of jury struts..
94. With the radio on and all trims centered,
adjust pushrods to make elevator level with
the horizontal stabilizer. (*Safety Note: Do
not plug in motor flight packs while adjusting
radio programming to prevent injury in case
the throttle is moved by accident.)
95. Apply full UP elevator and adjust either
mechanically or in radio programming to get
1-3/4” (45mm) travel measured at the
trailing edge. Also use 35% exponential to
soften the center travel (consult your radio
manual for how to do this). We recommend
a “low rate” setting of 1” (25mm) travel and
20% exponential.
96. Apply full down elevator and adjust for
1-3/4” (45mm) travel down and 35% Expo.
“Low rate” is 1” (25mm) and 20% expo.
