5
1. Locate the aileron assembly bag for the next
few steps.
2. Use your radio or our Manual Servo
Adjuster (p/n MSA725) to make sure the
aileron servo is centered. Install the servo
arm 90º to the servo and in the center of the
slot as shown.
3. Prepare servo attachment blocks for gluing.
Some trimming may be necessary.
4. While holding servo on plate, use 5min
Epoxy to glue blocks in place. Once dry, drill
(4) pilot holes in the wood blocks, then use
servo screws and rubber grommets to
secure servo in place.
