12. PCB PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
561
473
R50
1R0
5621
NOTES:
560
Ω
47k Ω
0.5 Ω
1 Ω
RD1/4PU J
RD1/4PU J
RN2H K
RS1P K
56 x 10
1
47 x 10
3
R50
1R0
561
473
5.62k Ω RN1/4PC F562 x 10
1
5621
Meaning of the figures and others in the parentheses in the parts list.
Example) IC 301 is on the point (face A, 91 of x-axis, and 111 of y-axis) of the corresponding
PC board.
IC 301 (A, 91, 111) IC NJM2068V
Mark No. Description Part No.
LIST OF ASSEMBLIES
1..DVD MT PCB ASSY A2L103A130
1..
OPERATION PCB ASSY(WYXZT5)* A2L103A270
1..
OPERATION PCB ASSY(WSXZT5)* A2L109A270
> 1..POWER PCB ASSY A2L103A240
(*) A2L103A270 and A2L109A270 have same service parts.
But they are NOT COMPATIBLE.
Mark No. Description Part No.
DVD MT PCB ASSY
SEMICONDUCTORS
IC 2301 IC AM5766 I1UFV5766S
IC 4001 IC MT1389FE/L-L IC8K0389L0
IC 4003 IC R3112N291A-TR-FA IE1F0291A0
IC 4004 IC AT26DF161-SU S2L101AF01
IC 4005 IC M12L64164A-7TG IF9J0164AG
IC 4006 IC LD1117AL-ADJ-AA3-A-R I1YF9117A0
IC 4007 IC R5523N001B-TR-F I1ZF0N0010
IC 4009 IC BA00BC0WFP-E2 I07F0C0WF0
IC 7301 IC LA73054-TLM-E I03FG30540
IC 7302 IC SN74CBT3257PWR I5CJ032570
IC 8003 IC RC4580IDR I04J045800
OTHERS
J 7302 RCA JACK 060R451013
J 8001 RCA JACK 060R401122
J 8003 RCA JACK 060R451012
X 4001 CRYSTAL (27MHz) 100GT02720
OPERATION PCB ASSY
SEMICONDUCTORS
IC 651 IC PT6315 IF4K063150
SWITCHES
SW 652-667 SWITCH TACT 0504R01T38
OTHERS
CP 602 CONNECTOR PCB SIDE 06G5AA1002
V 651 TUBE FLUORESCENT 096F80R401
OS 651 REMOTE RECEIVER 077Q040004
POWER PCB ASSY
RESISTORS
>
R 511 R,FUSE 68 OHM 1/4W R65584680J
OTHERS
J 8101 SOCKET, 21PIN 063D100050
Mark No. Description Part No.
