Pioneer DV-360-S User Manual

DV-360-S
67
5 678
56
7
8
C
D
F
A
B
E
1
Remove the six hooks.
2
Remove the front panel section.
Front Panel Section
2
1
Remove the four screws.
2
Remove the three screws.
3
Remove the DVDM Assy and stand it against the
other parts.
DVDM Assy
3
Front panel section
2
1
1
1
1
1
1
×2
×3
1 1 1
DVDM Assy
DVDM Assy
2
3
