DV-363-S
9
5678
56
7
8
C
D
F
A
B
E
EXTERIOR SECTION parts List
(2) CONTRAST TABLE
DV-363-S/KUXU, KCXU, KUXQ, DV-363-K/KUXU, KCXU and KUXQ are constructed the same except for the fol-
lowing :
Mark
No. Description Part No.
1 DVDM Assy VWS1555
>
2 POWER SUPPLY Unit VWR1365
(or VWR1367)
NSP 3 Loading Mecha. Assy VWT1207
4 Connector Assy PF13PP-D27
5 Flexible Cable (15P) VDA1963
6 Connector Assy (5P) VKP2301
NSP 7 PCB Spacer (3X6) AEC7156
8 Cord Clamper RNH-184
9 Rubber Foot VEB1349
10 PCB Support VEC2184
NSP 11 Base Chassis VNA2614
12 Rear Panel See Contrast table (2)
13 PCB Base VNE2278
14 Adapter 3L VNL1960
15 Adapter 3R VNL1961
16 DVD V Plate See Contrast table (2)
17 Tray Panel See Contrast table (2)
18 Bonnet Case S See Contrast table (2)
19 Screw See Contrast table (2)
20 Screw BBZ30P060FMC
21 Screw BBZ30P080FZK
22 Screw PPZ30P080FMC
Mark
No. Description Part No.
Mark No. Symbol and Description DV-363-S/KUXU DV-363-S/KCXU DV-363-S/KUXQ DV-363-K/KUXU DV-363-K/KCXU DV-363-K/KUXQ
12 Rear Panel VNA2536 VNA2536 VNA2536 VNA2533 VNA2533 VNA2533
16 DVD V Plate VAM1135 VAM1135 VAM1135 VAM1120 VAM1120 VAM1120
17 Tray Panel VNK5196 VNK5196 VNK5196 VNK5194 VNK5194 VNK5194
18 Bonnet Case S VXX2874 VXX2874 VXX2874 VXX2873 VXX2873 VXX2873
19 Screw BCZ40P060FNI BCZ40P060FNI BCZ40P060FNI BCZ40P060FZK BCZ40P060FZK BCZ40P060FZK
