(1) EXTERIOR (2) (XEUW5, XERD, XERI) SECTION PARTS LIST
(2) CONTRAST TABLE
DVH-760AV/XEUW5, DVH-765AV/XERD and DVH-765AV/XERI are constructed the same except for the following:
<NOTE>
Any component parts in the Deck (CD Mechanism Unit) of this model can not be supplied.
If you need to replace any parts in the Deck replace whole of Deck.
Mark No. Description Part No.
1 Screw 121040000054-FY
2 Shaft 121030000336-FY
3 Locker 121200000837000-FY
4 Washer 121440000031-FY
5 Gear 141200010082-FY
6 Bracket 141000011868-FY
7 Damper 121200000831000-FY
8 Screw 121104080020-FY
9 Handspike 141290001421000-FY
10 Spring 121035000625-FY
11 Screw 121040000185-FY
12 Frame 141000002723-FY
13 Screw 121106070011-FY
14 Screw 121104070029-FY
15 Top Cover 141000002220-FY
16 Screw 121100070059-FY
17 Screw 121101050013-FY
18 Screw 121104070008-FY
19 Screw 121104070026-FY
20 Screw 121104070007-FY
21 Bracket 141000002731-FY
22 Short Sheet 141000002864-FY
23 Cushion 121410000026-FY
24 Bolt 121050000003-FY
25 Spring 121035000861-FY
26 Dustproof 121450000126-FY
27 Bracket 141000031662-FY
28 Mat 121415000161-FY
29 Mat 121405000032-FY
30 Button (EJECT) 141230301924018-FY
31 Sponge 121405000004-FY
32 Button Cover 141000001855-FY
33 Mat 121405000040-FY
34 Rim 141270000712000-FY
35 Nut 121050000023-FY
36 Heat Silica Gel 121490000464-FY
* 37 CB Assy 843DM7240GLCB002 -FY
38 FFC 143820000257-FY
39 PCB 123010022809-FY
* 40 LB Assy 843DM7240GLLB002-FY
41 FFC 123820000486-FY
42 PCB 123010022808-FY
43 •••••
44 Cabinet 141240001459000-FY
45 Guide 141260000318000-FY
46 MB Assy 843DM7240GLMB002 -FY
47
•••••
48 •••••
49 Bracket 141000012561-FY
>
50 Fuse (10 A) 144800000076-FY
51 I/O 123830001555-FY
52 I/O 123830001767-FY
53 DVD Mechanism Module See Contrast table (2)
54 Screw 121104050032-FY
55 Heat Silica Gel 121490000426-FY
56 Shield 121000004199-FY
57 •••••
58 •••••
59 •••••
60 Wire Harnes 123830000117-FY
61 FFC 143820000228-FY
62 SB Assy See Contrast table (2)
63 Deck 144840000102-FY
64 Shield 121000004351-FY
65 Heatsink 141015000300-FY
Mark
No. Description Part No.
Mark No. Description DVH-760AV/XEUW5 DVH-765AV/XERD DVH-765AV/XERI
53 DVD Mechanism Module 843DM7240GRSB002 843DM7240GLSB002-FY 843DM7240GMSB002-FY
62 SB Assy 842DM7240GRSB002 842DM7240GLSB002 842DM7240GMSB002
