DECK MECHANISM UNIT PARTS LIST
1 Assy’y HD Holder 50-093-4373
3 Frame HD 50-219-3024
4 Plate AZ 50-119-4046
5 Spring AZ 50-160-4108
6 Lever HD 50-259-3342
7 R/P Head TC881CB067B
9 Guide Tape 50-219-4038
10 Plate HD 50-093-3036
11 Chassis HD 50-112-3045
12 Cap Pinch R 50-219-4033
13 Cap Pinch L 50-219-4034
14 Roller Pinch 50-027-41054
15 Ass’y Plate D 50-219-4311
16 Cap Reel 50-228-4020
17 Gear Reel 50-222-4006
18 Lever ST 50-259-4041
19 Guide C 50-219-4014
20 Lever Brake 50-259-3251
22 Arm SW 50-239-4027
23 Arm CS 50-239-4026
25 Ass’y Cover 50-093-4063
27 Arm Trigger 50-268-3016
28 Arm Cam 50-139-4292
29 Gear Cam 50-221-3009
30 Coller 03-300-4455
31 Ass’y Flywheel RA 50-093-3360
32 Ass’y Clutch 50-093-4069
33 Arm UD A 50-239-4017
34 Gear UD 50-222-4007
35 Pulley D 50-223-4254
36 Plunger 03-300-4442
37 Ass’y Bobbin 50-093-4125
39 Ass’y Motor 50-093-4316
41 Belt BR 02-084-4205
42 Belt AF 02-084-4202
43 Belt FR 02-083-4188
45 PCB HD 50-070-4057
46 Housing S5BPHKS
50 Ass’y PCB 50-093-4057
51 Ass’y Flywheel L 50-093-3315
52 Ass’y Flywheel RB 50-093-3361
60 Spring 01-081-4601
61 Spring 01-082-4652
62 Spring 01-082-4651
63 Spring 01-082-4650
64 Spring 01-080-4649
65 Spring 01-080-4607
66 Spring 01-080-4635
67 Spring 01-082-4654
68 Spring 01-082-4598
69 Spring 01-082-4597
70 Spring 01-081-4657
71 Spring 01-081-4605
80 Screw GSE10A2003
81 Screw GSE20A2005
82 Screw GSE10A2004
83 Screw GSD10A2018
84 Screw 03-300-4056
85 Screw GSL10A1704
86 Screw GSP10A2603
87 Screw GSP11A2012
88 Screw GSE20A2004
89 Screw GSL20A2005
90 Screw 03-300-4127
100 Washer GWN21X040040
101 Washer GWM19X055035S
102 Washer GWM19S035035
103 Washer GWM17S050035S
104 Washer GWM48X075010
105 Washer GWP23X040020
106 Washer GWP21X045020
107 Washer GWP12X030040S
