Hook the VESA Plate-b to the Socket on
the fully extended arms.
5
Secure the VESA
Plate-b to the
articulating arm using
the 2x M4 Bolt-d
provided.
Use the wrench
provided to adjust the
tilting angle of the
VESA Plate-b.
2 x M4 Bolt - d
6
