6
AA/LR6 Battery Installation
Using the Battery Grip
Specifications
1. Insert the batteries into the Battery Magazine BGM-E9A (for Batteries). (Fig.7)
Make sure the +and –battery contacts are properly oriented as shown in the
figure.
2. Attach the battery magazine into the battery grip. (Fig.8-1)
3. Close the release handle. (Fig.8-2)
Less images can be shot when using size-AA/LR6 batteries. Also, the number
of possible shots may vary depending on the batteries brand and storage
conditions, so usage of size-AA/LR6 batteries is recommended only for
emergencies.
When using with non-rechargable size AA/LR6 batteries, please use when
temperature is above 20℃ . The camera may not work when used in low
temperature or when old and new batteries are used together.
1. Turning the vertical-grip operation switch to (ON)(Fig.9)make the battery
grip buttons and dial function in the same way as those on the camera.
2. When shooting in the horizontal-grip position, turn the vertical-grip operation
switch to (OFF) so that you do not accidentally use the buttons or dial on the
battery grip.
3. The battery power level can be checked on the camera.
The product specifications and exterior are subjected to change without notice.
This manual information is updated at 1st Oct, 2011. If you wish to use this
product combined with other Pixel products published after this date; please
consult with the PIXEL dealer for further information.
Now you can start to use incredible PIXEL product. If you have any question,
please contact your local dealer or visit to http://www.pixelhk.com.
Battery: 1 or 2 of LP-E6 Battery, Or 6pcs AA/LR 6 Alkaline Battery
Power switch: Camera's Power Switch
Working temperature: 0℃-+40℃
Working humidity: 85% Or Less
Dimensions: Approx.150.1(W)x116.7(H)x84.9(D)mm
Weight: Approx.248.8 g(without batteries and battery magazine)
