PK TX - Step 2: Connecting Stand Components; Grill Capsule Assembly; Step 1: Positioning the Bottom Capsule; Step 2: Installing Grates

ASSEMBLY INSTRUCTIONS
PAGE
4
1) Place grill bottom capsule on PK-
TX™ stand oriented as shown. Ensure
the capsule sits down securely on the
cross bars.
Hinge side of grill
2) Place charcoal grate and hinged
cooking grid inside grill bottom
capsule.
3. Attach upper tube section to lower
tube section and secure with provided
hardware as pictured.
4. Attach shelf mount section to lower
tube section and secure with provided
hardware as pictured.
GRILL CAPSULE ASSEMBLY STEPS (i f n e e d e d ):
STEP
2
