INSTALLATION
2
Unpacking and positioning
1. Unpack the appliance carefully. Dispose of the packaging as described in
chapter waste management.
2. Completely remove the transport-protection. Be very careful and do not use any
aggressive or abrasive detergents to remove residuals of the transport-
protection.
3. Check that the appliance and the power cord are not damaged.
4. Connect the appliance to a dedicated socket only.
5. Do not install the appliance in a place where it may come in contact with water
or rain; otherwise the insulation of the electrical system will be damaged.
Installation / hob
A. Selection of installation equipment
Cut out the installation hole as described on the drawing below. For installation
and use, a minimum of 50mm space shall be preserved around the hole. The
thickness of the work top should be at least 30 mm. Choose heat-resistant materials
for the work top only to avoid any deformation caused by the heat-radiation of the
appliance.
L(mm)
W(mm)
H(mm)
D(mm)
A(mm)
B(mm)
X(mm)
590
520
55
51
560
490
50 mini
The appliance must be ventilated properly. Do not block the air outlet and inlet.
Ensure the ceramic cooker hob is in proper operating state. The safety distance
between the hob and a cupboard above should be at least 760 mm.
