24
A(mm)
B(mm)
C(mm)
D
E
760
50 min.
20 min.
Air inlet
Air outlet 5 mm
B. Before locating the fixing brackets
1. Place the appliance on a stable, smooth surface (use the packaging). Do not
exert physical force to the controls of the hob.
2. For fixing the appliance on the worktop you must screw the 4 brackets on the
bottom after installation.
A
Screw
B
Bracket
C
Screw hole
D
Base
