Installation EDF
Insert the BEC controller
from the front here to
connect the EDF
The EDF must line up
with the rear edge, then
drill holes for the screws
The cover is attached with six fl at
screws 2 * 8mm. If your EDF protrudes
further, something needs to be cut off
on the cover.
