AC8D 8” (20 cm) Subwoofer
Dual 4 Ω Voice Coils
1200 W Peak Power Handling
Customizable Trim Ring
Operates in a compact enclosure
2
4
Enclosures
The AC8D is designed to work in a very compact sized sealed
enclosure, 0.35ft³. Since the woofer has pole-vent, it needs a mini-
mum clearance from the rear wall of the enclosure of 0.75” (19 mm).
Below you will find the dimensions to make the enclosure to suit the
subwoofer, it has been designed for maximum output while retaining
great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 10” (254 mm)
Width (W) : 10” (254 mm)
Height (H) : 10” (254 mm)
Cutout Diameter: 7” (177.8 mm)
Enclosure Dimensions
