TQ12S 12” (30cm) Subwoofer
x Single 4 Ω Voice Coil
x 1500 W Peak Power Handling
x Treated Paper Cone
x Large Foam Surround
2 4
Enclosures
The TQ12S is designed to work in a medium sized sealed or ported
enclosure . Since the woofer has pole-vent, it needs a minimum
clearance from the rear wall of the enclosure of 0.75” (19 mm).
Below you will find the dimensions to make the enclosure to suit the
subwoofers needs, it has been designed for maximum output while
retaining great sound quality.
The dimensions have already accounted for the volume displacement
of the subwoofer, and using 3/4” (19mm) MDF. All dimensions are
external.
Sealed Dimensions:
Length (L) : 15” (381 mm)
Width (W) : 12” (304.8 mm)
Height (H) : 13” (330.2 mm)
Cutout Diameter: 11” (279 mm)
Ported Dimensions:
Length (L) : 20” (508 mm)
Width (W) : 12” (304.8 mm)
Height (H) : 14” (355.6 mm)
Port Diameter : 4” (101.6mm)
Port Length : 12” (304.8 mm)
Port Freq : 34 Hz
Cutout Diameter: 11” (279 mm)
Enclosure Dimensions
