PLANET ECLIPSE CS3 - Page 32

C S 3
32
MAINTENANCE
SE RVIC ING IN T ERVA LS
FIG .1
FIG .2
A
B
FIG.1
When the Lubrication Required indicator A is displayed, the user
needs to perform a simple lubrication procedure to maintain the
marker’s peak levels of performance and reliability. We have a
maintenance video outlining this procedure, see page 33.
LUBRICATION REQUIRED
The marker has fired a sufficient number of shots to
warrant lubrication.
After lubrication the lubrication counter can be reset with
SERVICING > RESET > LUBE.
FIG.2
When the Service Required indicator B is displayed, the user needs
to perform a more involved set of procedures to maintain the
marker’s peak levels of performance and reliability. See page 33.
SERVICE REQUIRED
The marker has fired a sufficient number of shots to
warrant a service.
After a service the service counter can be reset with SERVICE
> RESET > SERVICE. Resetting the service counter also resets
the lubrication counter.
