PLANET ECLIPSE CS3 - Page 44

ELECTRONICS
US ER INT E RFA CE PARA METE RS
C S 3
44
FIG .4
FULL PARAMETER
The amount of time that the breech has to be
full (paintball in place) before the marker
registers that it is actually full.
> Range : 1.0 - 20.0 ms (milliseconds) in
0.1 increments.
FIG .3
EMPTY PARAMETER
The amount of time that the breech has to be
empty before the marker registers that it is
actually empty.
> Range : 1.0 - 20.0 ms (milliseconds) in
0.1 increments.
FIG .2
DEBOUNCE PARAMETER
Amount of trigger debounce. Changing this
parameter directly changes the PULL TM and
RELEASE TM parameters.
> LEVEL1: Least filtering (most
trigger bounce).
> LEVEL9: Most filtering (least
trigger bounce).
FIG .1
FILTER MENU
The FILTER parameters are used to tune the
software filters to prevent the marker from
firing, unless all of the necessary conditions
are met.
Factory default settings are suitable for most
set-ups however, certain loader and trigger
set-ups may require filter adjustments.
