C S 3
07
INTRODUCTION
SE TTIN G U P
FIG.1
A SWITCH MARKER OFF BEFORE YOU BEGIN.
B BUILD THE 3-PIECE S63 BARREL.
Slide the insert into the back section.
Rotate the barrel tip counter-clockwise onto the back.
C ATTACH THE COMPLETE BARREL TO THE MARKER.
Rotate the barrel clockwise into the marker body.
D FIT A BARREL BLOCKING DEVICE FOR SAFETY.
E ENSURE THE MARKER IS DE-GASSED.
Push and hold the POPS button then slide the POPS bonnet
away from the POPS body.
F ATTACH A PRE-SET AIR SYSTEM.
Rotate the air system clockwise into the POPS body.
G LOOSEN THE CLAMPING FEEDNECK.
Open the feedneck lever away from the feedneck.
Rotate the feed wheel counter-clockwise.
H ATTACH A LOADER.
I SECURE THE LOADER.
Rotate the feed wheel clockwise to tighten.
Close the feedneck lever to secure.
J GAS THE MARKER.
Push the POPS bonnet into the POPS body until it engages.
K SWITCH ON THE MARKER.
! IMPORTANT! To switch ON/OFF see page 08.
! DO NOT over-tighten the barrel.
! ALWAYS ensure marker is de-gassed when setting up.
! NEVER use CO2. Only use compressed air or Nitrogen.
WARNING !
Always make sure that the marker is OFF with a barrel blocking device installed and
that no paintballs are in the marker or loader before attaching an air system.
Compressed air and nitrogen systems can be extremely dangerous if handled or
used incorrectly.
Only attach an air system certified for use within the country of use.
Never add lubricants or grease into the fill adaptor of the air system regulator.
Ensure that all screws are tightened and no parts are loose before installing an air
system.
Do not pressurise the marker without the bolt system correctly installed, as high
pressure gas will be emitted.
Do not install a compressed air system or load paintballs into the marker until you
feel confident with your ability to handle the marker safely and responsibly.
