C S 3
08
INTRODUCTION
SU B TI TLE
C S 3
08
INTRODUCTION
SWITCHIN G THE M ARKE R O N/O F F
FIG.1
The navigation console houses the breech sensor (BS) status
indicator A ; the navigation buttons: Up B Select C Down D ; and the
OLED screen E .
SWITCHING ON
Press and hold Select ( or double-click it * ) until the marker powers
up. The LED A will flash to indicate the BS status.
See page 15 for BS status indicator references.
SWITCHING OFF
Press and hold Select until TURN OFF? is displayed. Press Select
again to switch off.
FIRING THE MARKER
Pull the trigger to fire. The BS status indicator (LED) and the breech
sensor indicator (OLED) will indicate if the marker is able to fire.
To toggle the breech sensor on/off push and hold Up for 0.5 seconds
when the marker is on. See page 10 for BS indicator states.
* Double-click can be disabled in the HARDWARE menu (page 48).
WARNING!
DO NOT dry fire your marker as this may lead to damage over a sustained period.
FIG .1
B
C
D
E
A
