THE EGO10 NAVIGATION
CONSOLE
At the rear of the Ego10 grip frame you will nd the
navigation console FIGURE 1.5 which is used for:
> TURNING THE EGO10 ON AND OFF USING THE
BUTTON
> SCROLLING THROUGH MENUS WITH THE
AND BUTTONS
> SELECTING PARAMETERS TO EDIT USING THE
BUTTON
> EDITING PARAMETERS USING THE AND
BUTTONS
> TURNING THE EGO10 BREAK BEAM SENSOR
SYSTEM ON AND OFF USING THE BUTTON
PUSH AND HOLD
> RESETTING RECORDED VALUES USING THE
BUTTON PUSH AND HOLD
> CONTROLLING THE GAME TIMER WITH THE
BUTTON QUICK PUSH AND RELEASE
> SCROLLING THROUGH THE VARIOUS RUN
SCREENS USING THE BUTTON QUICK PUSH
AND RELEASE
>DISPLAYING THE CURRENT PRESET LOADED ON
THE EGO10 USING THE BUTTON QUICK PUSH
AND RELEASE
NOTE: THE COLOUR OF THE BACKLIGHT ON THE EGO10
LCD SCREEN CAN BE CHANGED BY ADJUSTING THE RED,
BLUE AND GREEN LEVEL PARAMETERS. SEE PAGE 4344 FOR
FURTHER DETAILS.
NEXT / LOWER
PREVIOUS /
RAISE
SELECT
FIG 1.5
WARNING: THE BACKLIGHT ON THE LCD DISPLAY
TURNS OFF AFTER A PERIOD OF TIME. WHEN THIS
HAPPENS THE MARKER IS STILL ON AND ABLE TO FIRE.
TO ADJUST THE LCD BACKLIGHT SEE PAGE 4344
