PLANET ECLIPSE EGO TEN - Ego10 Orientation Guide

6 ORIENTATION
Names the component parts of the Ego10 Marker. This
section is essential reading for everyone.
6 > KNOW YOUR EGO10
7 > ECLIPSE SHAFT 3 BARREL
8 > INLINE REGULATOR
9 > LOW PRESSURE REGULATOR
10 > EGO10 SOLENOID ASSEMBLY
11 > EGO10 BOLT ASSEMBLY
12 > THE EGO10 NAVIGATION CONSOLE
13 > OPERATIONAL OVERVIEW
14 QUICK SETUP
Details on how to get up and running quickly with your
Ego10. This section is essential reading for everyone.
15 > INSTALLING A 9V BATTERY
16 > SWITCHING ON THE EGO10
> SWITCHING OFF THE EGO10
> FIRING THE EGO10
> THE EGO10 CIRCUIT BOARD
17 > USING THE BREAK BEAM SENSOR SYSTEM
18 USING YOUR EGO10
More detailed information on how to use and interact
with the Ego10 via its user interface.
18 > SETTING UP
> INSTALLING A PRESET AIR SYSTEM
19 > TSLOT MOUNTING SYSTEM
> MACROLINE HOSING AND ELBOWS
20 > INSTALLING AN ADJUSTABLE AIR SYSTEM
21 > ATTACHING A LOADER
22 > SETTING THE TRIGGER
24 > ADJUSTING THE VELOCITY
> ADJUSTING THE LPR PRESSURE
25 > USER INTERFACE
> RUN SCREEN LAYOUT
26 > THE BBSS INDICATOR
> THE AUX OUT INDICATOR
27 > THE SOUND INDICATOR
> THE TRIGGER DETECTION
INDICATOR
28 > THE LOCK INDICATOR
> THE BATTERY LEVEL INDICATOR
> THE GAME TIMER
> THE SHOT COUNTER
29 > THE ACTUAL RATE OF FIRE
> THE PEAK RATE OF FIRE
> THE MENU SYSTEM
30 MENU TREE
A quick reference guide to the user interface.
34 ADVANCED SETUP
In depth information on setting up the Ego10.
34 > ACCESSING THE MENU SYSTEM
> MOVING AROUND THE MENUS
> ALTERING PARAMETERS
35 > THE MAIN MENU
36 > PRESET -The Preset Menu
> LOAD -The Load Preset Parameter
> SAVE -The Save Preset Parameter
37 > FIRE MODE -The Fire Mode Parameter
> ROF CAP -The Rate of Fire Cap Parameter
> BS ON ROF -The Maximum Rate of Fire Parameter
>
BS OFF ROF - Rate of Fire With BBSS O Parameter
38 > RAMP SETUP -The Ramp Set-up Menu
> TYPE -The Ramp Type Parameter
> RATE -The Linear Ramp Rate Parameter
39 > SEMI SHOTS -The Ramp Start Parameter
> KICK IN -The Ramp Kick-In Parameter
> SUSTAIN -The Sustain Rate Parameter
> RESTART -The Ramp Restart Parameter
> TIMING -The Timing Menu
40 > DWELL -The Dwell parameter
> FSD COMP -The First Shot Drop-o
Compensation Parameter
> FSD DLY -The First Shot Drop-o
Delay Parameter
> FILTER -The Filter Menu
4.
CONTENTS
