SCREW QTY DESCRIPTION
PCB SCREW (3), BEARING CARRIER SCREW (2)
( M2.5 x5 CAP HEAD SOCKET)
SOLENOID SCREW (2)
( M2.5 x6 CAP HEAD SOCKET)
RUBBER GRIP SCREW (6), BBSS COVERS SCREW (2)
( 6-32UNC x5/16 COUNTERSUNK SOCKET)
SHORT FEED NECK SCREW
( 1 x10-32UNF x1/2 CAP HEAD SOCKET)
INLINE REGULATOR ADJUSTER SCREW
( CUSTOM MANUFACTURED)
MICROSWITCH SCREW
( 6-32 UNC x1/2 SOCKET SET SCREW)
TRIGGER ADJUSTMENT SCREW
( 6-32 UNC x3/16 SOCKET SET SCREW)
OOPS SCREW
( 10-32 UNF x1/2 SOCKET SET SCREW)
VALVE PLUG
( CUSTOM MANUFACTURED)
LPR ADJUSTER SCREW
( CUSTOM MANUFACTURED
SHORT FRAME SCREW
( 10-32 UNF x3/8 SOCKET BUTTON HEAD)
5
2
8
1
1
1
4
2
1
1
2
CLAMPING FEED SPROCKET SCREW
(CUSTOM MANUFACTURED)
FRM RETAINING SCREW
( CUSTOM MANUFACTURED)
1
1
TRIGGER PIN RETAINING SCREW
( 6-32 UNC x1/8 SOCKET SET SCREW)
1
