THE GEO2 NAVIGATION
CONSOLE
At the rear of the Geo2 grip frame you will nd the
navigation console FIGURE 0.1 which is used for:
> TURNING THE GEO2 ON AND OFF USING THE
BUTTON
> SCROLLING THROUGH MENUS WITH THE
AND BUTTONS
> SELECTING PARAMETERS TO EDIT USING THE
BUTTON
> EDITING PARAMETERS USING THE AND
BUTTONS
> TURNING THE GEO2 BREAK BEAM SENSOR
SYSTEM ON AND OFF USING THE BUTTON
PUSH AND HOLD
> RESETTING RECORDED VALUES USING THE
BUTTON PUSH AND HOLD
> CONTROLLING THE GAME TIMER WITH THE
BUTTON QUICK PUSH AND RELEASE
> SCROLLING THROUGH THE VARIOUS RUN
SCREENS USING THE BUTTON QUICK PUSH
AND RELEASE
NEXT / LOWER
PREVIOUS /
RAISE
SELECT
FIG 0.1
WARNING: THE BACKLIGHT ON THE LCD DISPLAY
TURNS OFF AFTER A PERIOD OF TIME. WHEN THIS
HAPPENS THE MARKER IS STILL ON AND ABLE TO FIRE.
TO ADJUST THE LCD BACKLIGHT SEE PAGE 4142
12.
