Step 2: Attaching the Stand
Mounting the stand at the media phone rear panel, make sure the latch on the
stand and the hole on the media phone matched. Hold the stand and pull down
gently.
Step 3: Connecting AC Power and Network
Connect an Ethernet cable from your desktop computer to the PC port on the
Media Phone. Plug the other end of the Ethernet cable into your already prepared
network con-nection .
1. Use the power adapter shipped with the unit to ensure correct
functionality.
2. The Media Phone supports IEEE 802.3af at its Network port
and can be powered from IEEE802.3af PSE (Power Sourcing
Equipment) Either power from AC adapter or from 802.3af is
required.
