Planet POE-161 User Manual

12
POE-161S:
Product POE-161S
Hardware Specication
Interface
“Data” Out Port 1 x RJ-45 STP
“PoE (Power+Data)”
Input Port
1 x RJ-45 STP
DC Out Plug
Connector
1
LED Indicator System: PoE In x 1 (Green)
Network Cable
10Base-T: 2-Pair UTP Cat. 3, 4, 5,
up to 100m (328ft)
100Base-TX: 2-Pair UTP Cat. 3, 4, 5,
up to 100m (328ft)
1000Base-T: 2-Pair UTP Cat. 5, 5e, 6
up to 100m (328ft)
EIA/TIA- 568 100-ohm STP (100m)
Data Rate
10/100/1000Mbps
(vary on Ethernet device attached)
DIP Switch 5V DC / 12V DC output voltage
Dimension (W x D x H) 95 x 70 x 25 mm
Weight 111g
Number of device can be
powered
1
Operating Temperature 0 ~ 50 Degree C
Storage Temperature -10 ~ 70 Degree C
Humidity 5 ~ 95% (Non-condensing)
Power over Ethernet
PoE Standard
IEEE 802.3at High Power over Ethernet
pre-standard / PD
