VERIFY THE CONTENTS INSIDE
THE PACKAGE BOX
The package should contain the following items plus
VIP-1120PT. If any item is missing or damaged, please
contact the seller immediately.
Quick Installation Guide Handset Cord Handset
Stand RJ45 Cable
Step 1. Handset Connection
Plug one end of the handset cord into the handset and the
other end into the handset jack
Step 2. Connecting Power System
The VIP-1120PT can be powered either by external AC/DC
adapter or by connecting to an IEEE 802.3af/at PSE device
such as 802.3af injector/hub or 802.3af/at PoE switch.
Once the VIP-1120PT is powered, the LCD screen will
prompt for POST.
PoE Switch
Power Adapter
(Optional)
Note
1. This unit does not include the 5V/600mA
power adapter.
2. Only WAN supports PoE.
Step 3. Connecting Network
PC
Internet
PoE Switch
IP PBX
Step 4. Computer Network Setup
Set your computer’s IP address to 172.16.0.x, where x is
a number between 2 to 254 (except 1 which is being used
for the phone by default). If you don’t know how to do this,
please ask your network administrator. Connect your PC to
VIP-1120PT PC port.
PC
To Next Page
