Dingo 2020N User Guide
20
Further information
This controller is capable of more than what is described in this
user manual.
For information on how to customise your regulation setup and
set up larger systems, as well as the many additional features,
consult the Reference Manual. This can be downloaded from
our website.
Accessories
These accessories can enhance the usefulness of your controller.
External Battery Temperature Sensor (DT or DTB)
The DT is a plastic-cased unit for direct attachment to the battery
wall. The DTB has a bolt-on lug for attaching to the battery terminal
(either terminal). It connects to the T+ and T- inputs on the
green plug-in terminal block under the wiring cover. See Section
7.4.3 of the reference manual for details.
The following accessories plug into the serial port socket. (RJ11)
External Shunt Adaptor (DSA)
Up to four external shunts can be added to the controller to allow it
to measure larger currents than it is capable of measuring directly. The
shunt adaptor measures the current in a shunt (eg SH200), converts it
to digital information and sends that information to the controller. The
shunt connection is isolated so the shunt can be placed in any part of
the circuit. Currents up to +/-250A can be read in 0.1A steps.
