Step 1
• Screw twelve 1” self-tapping screws through two Top Ledges and two Bottom Channels into one
Corner Post and two Wall Panels to build a Corner Section as pictured below.
Note: Screws for the Top Ledges should be located only on the outer/dry side of the pool. Before
screwing for easier screwing, please pre-drill all the necessary openings by using a 1/8” drill bit through
the factory pre-drilled ¼” openings.
• Use the pre-drilled holes located on the Top Ledges and Bottom Channels as your guide.
IMPORTANT: When placing two Top Ledges over the Wall Panels at the corner, please make
sure that you put them a little bit farther from the Corner by all means, making a very small gap
between the Corner and Top Ledges and providing the place for locating the Corner Cap later
(please see two pictures below).
Pre-assembling Corner Sections:
