Installation Instructions

Models XX0193 and XX0193S

ECN2716

Page 11 of 14

Bill of Materials

XX0193 - UNITY ROCKER

PART NO. DESCRIPTION QTY.

AAU0062 CASTING - 7.09" O.D. SPRING WEDGE 6

AAU0843 HUB - 7.00" O.D. x 1.72" - CAST 1

AAU0844 COVER - 7.50" O.D. x 1.04" - CAST 1

AAU0845 UNITY ROCKR HAND HOLD 6

AFR1701 ANCHOR - 34.38" x 27.00" x 24.99" 1

AFR1702 FRAME - UNITY ROCKR 1

APL2268 PLATE - 28.84" x 24.99" x 12 GA 1

ATM0093 SPRING - 300MM 3

BAD0085 THREAD LOCKING ADHESIVE 1

BAE0029 BOLT - .38"-16 x .89" x 2.50" - U 6

BAE0036 BOLT - .38"-16 x .89" x 1.75" - U 6

BAE0595 WASHER - 3/8" SAE FLAT 6

BAE0600 WASHER - 1" O.D. FLAT 162

BAE0620 NUT - 3/8"-16 LOCK w/NYLON CAP 51

BAE0621 NUT - 3/8"-16 ZINC HEX w/LOCKING RING 36

BAE0664 BOLT - 3/8"-16 x 1.00" BUTTON HEAD - SS 72

BAE0665 BOLT - 3/8"-16 x 1.75" BUTTON HEAD - SS 6

BAE0922 TOOL - TT 45 L WRENCH 1

BAE1798 BOLT - 3/8"-16 x .89" x 3.25" - U 6

BAE06675 BOLT - 3/8"-16 x 2.25" BUTTON HEAD - SS 3

BFC3625 SHEET - 28.84" x 24.99" x .75" 1

BPM0322 ROCKR PERF SHEET - LEFT 6

BPM0323 ROCKR PERF SHEET - RIGHT 6

ALB0025 LABEL - AGE APPROPRIATE SHEET 1

1000 Buffalo Road • Lewisburg, PA 17837

www.playworldsystems.com

For Customer Service, Call

800-233-8404 or

570-522-9800

OUTSIDE U.S.

XX0193S - UNITY ROCKER SURFACE MOUNT
