PLD PLD4.2 - Page 13

13
TD-000368-01-A
— Figure 17 —
F5: AB C+D
F5: AB C+D
AB Parallel
C+D Bridged
1
AB
3
C+D
The following are electrically
the same point
A (1+) and B (1+)
A (1-) and B (1-)
X (2+) and Y (1+)
X (2-) and Y (1-)
AB X
2+
2-
CD Y
1+
1-
1-
1+
1+
1-
= Subwoofer
= Mid Range
Optional
— Figure 18 —
F4: AB CD
F4: AB CD
AB Parallel
CD Parallel
The following are electrically
the same point
A (1+) and B (1+)
A (1-) and B (1-)
C (1+) and D (1+)
C (1-) and D (1-)
= Subwoofer
= Mid Range
1
AB
3
CD
Optional
A
C
B
D
X
Y
1+
1-
1+
1-
1+
1-
1+
1-
— Figure 19 —
F7: ABC D
F7: ABC D
1
ABC
4
D
ABC Parallel
D Single
The following are electrically
the same point
A (1+), B (1+), and C (1+)
A (1-), B (1-), and C (1-)
= Subwoofer
= High Range
Optional
AB X
1+
1-
CD Y
1+
1-
1+
1-
1+
1-
Three-Channel Confi gurations
— Figure 20 —
F3: Config - A+B C D
F3: Config - A+B C D
A+B Bridged
C Single
D Single
1
A+B
3
C
4
D
= Subwoofer
= Mid Range
AB X
CD Y
1+
1-
= High Range
1+
1-
1+
1-
